Repair Parts List for 7 and 8” Bench Grinders

2LKR8 and 2LKR9

Dayton Operating Instructions and Parts Manual

7

(Δ) Not shown.

(†) Not available as repair part.

(*) Standard hardware item, available locally.

1 #10-24 x 7/8” Pan head screw * – 10

1 #10-24 x 1/2” Pan head screw – * 10

2 Wheel guard 26083.00 26056.00 2

3 Spark guard (set of 2) 25815.00 25815.00 1

4 Wheel guard cover 16637.02 24496.02 2

5 Flange 24497.00 24497.00 2

6 5/8”-11 Hex nut (LH thread) 00088.00 00088.00 1

7 Inner wheel flange 24498.00 24498.00 2

8 Grinding wheel (36 coarse grit) 6A087 6A090 1

9 Grinding wheel (60 med. grit) 6A088 6A091 1

10 5/16-18 x 1” Knob 25812.00 25812.00 2

11 3/8-16 x 3/4” Hex head bolt * * 2

12 3/8” Flat washer * * 4

13 5/16” Flat washer * * 2

14 1/4-20 x 3/8” Knob 25816.00 25816.00 2

15 Dust collector hose 08070.00 08070.00 1

16 Tool rest (left) 25813.00 25813.00 1

17 Bracket (left) 31447.00 31447.00 1

18 3/8” Lock washer * * 2

19 3/8-16 x 1/2” Knob 25817.00 25817.00 2

20 #10-24 x 3/8” Pan head screw * * 4

21 Upper eyeshield bracket (left) 25177.00 25177.00 1

22 Upper eyeshield bracket (right) 25188.00 25788.00 1

23 Eyeshield 00281.00 00281.00 2

24 Lower eyeshield bracket 00280.00 00280.00 2

25 Tool rest (right) 25825.00 25825.00 1

26 5-0.8 mm Hex nut * * 4

27 1/4-20 x 1/2” Hex head bolt * * 6

28 5-0.8 x 228mm Flange screw 16654.00 16654.00 4

29 Endshield 16627.02 16627.02 2

30 Bearing 6204ZZ 1L017 1L017 2

31 Motor fan 01620.00 22041.00 1

32 Armature † † 1

33 Stator with housing † † 1

34 Grommet 01066.00 01066.00 1

35 Line cord 00067.00 00090.00 1

36 Strain relief 04055.00 04055.00 1

37 #10-24 x 1/4” Flange screw 03210.00 – 7

37 #10-24 x 1/4” Flange screw – 03210.00 9

38 Base 24499.02 24499.02 1

39 Switch with key 08066.01 08066.01 1

40 Base cover 24500.00 24500.00 1

41 1/4” Lock washer * * 8

42 1/4”-20 Hex nut * * 2

43 Capacitor clamp – 16655.00 1

44 Capacitor 16895.00 16646.00 1

45 #10 Serrated washer * * 5

46 Base bumper 23991.00 23991.00 4

47 Wavy washer 16640.00 16640.00 2

48 Bracket (right) 31448.00 31448.00 1

49 Centrifugal switch – 25172.00 1

50 #10-24 x 3/8” Flange screw 03207.00 03207.00 1

51 5/8”-11 Hex nut (RH thread) 00087.00 00087.00 1

52 Stationary switch – 25171.00 1

Recommended Accessories

Δ Cast iron tool stand 4Z154 4Z154 1

Δ Lighted eyeshield 6X854 6X854 1

Δ Grinding wheel dresser 2X951 2X951 1

Δ Large grinding wheel dresser 6Z851 6Z851 1

Δ Multi-purpose stand 6LM26 6LM26 1

Δ Spacer kit 1LNE6 1LNE6 1

Ref. Part No. For Models

No. Description 2LKR8 2LKR9 Qty.

Ref. Part No. For Models

No. Description 2LKR8 2LKR9 Qty.
